D-XF60-ABC: High-Altitude Firefighting Drone with 60kg Payload Capacity for Emergency Response

2026-04-23 0 Drones 4357℃

Industrial Firefighting Solution

D-XF60-ABC: High-Altitude Firefighting Drone with 60kg Payload Capacity for Emergency Response

The D‑XF60‑ABC redefines aerial firefighting by combining extreme 60 kg payload capacity with cutting‑edge flight technology. Designed for emergency response teams who need reliable performance when seconds matter.

Key Specifications

⚖️
60 kg
Max Payload

🛩️
1,200 m
Max Altitude

🔋
60 min
Flight Time

📡
30 km
Control Range

💧
IP68
Waterproof

🌬️
Level 7
Wind Resistance

Technical Excellence for High‑Impact Missions

At the heart of the D‑XF60‑ABC lies a multi‑core flight control platform that synchronizes GPS, GLONASS, and visual positioning for 0.1 m hover accuracy. The drone offers three power modes:

S Mode: 21 m/s maximum speed for rapid response
M Mode: 16 m/s balanced performance
P Mode: 12 m/s for precision operations

In industrial power mode, the aircraft sustains up to 60 minutes of flight time, providing an extended window for sustained aerial firefighting operations.

Heavy Payload Accessories

🔥 High-Pressure Fire Hose

Sprays 24 L/min at 3–5 Mpa pressure

💨 Fine-Powder Canister

50-liter capacity for rapid suppression

🚿 Electromagnetic Booster Pump

Projects water up to 200 m distance

🔫 Window-Breaking Extinguisher

Laser-guided 80 mm caliber, 10–25 m range

🛡️ Safety Features
Dual-backup flight control system for seamless failover
Level 7 wind resistance (instantaneous Level 8)
Intelligent obstacle avoidance with radar and visual sensors
Electronic fence for collision prevention
Modular battery swap in under 2 minutes

Versatile Applications Across Industries

Beyond direct firefighting, the D‑XF60‑ABC excels in multiple emergency response scenarios:

🏗️

Material Transportation

Lifts up to 60 kg of supplies to inaccessible locations—disaster-hit zones, mountainous terrain, or skyscraper rooftops.

💥

Ultra-Fine Powder Deployment

Deploys extinguishing balls covering 15–20 m² each for rapid suppression across wide fire areas.

📢

Emergency Broadcast

Integrated 120 dB loudspeaker broadcasts evacuation commands and warnings.

🎯

Precision Targeting

Laser aiming device ensures precise targeting of high-pressure nozzles.

Optional Imaging Systems

30× Optical Zoom Camera: Detailed situational assessment
Thermal Imaging Gimbal: Real-time heat mapping and fire spread monitoring

📦 Portability & Deployment

The robust carbon-fiber frame folds to a compact 750 × 650 × 800 mm for rapid transport. The drone can be airborne within minutes of arrival, deployable from vehicles or rooftops.

AI-Driven Intelligence

The integrated ground control software offers:

Real-time telemetry monitoring
AI-based diagnostic alerts for battery health, motor temperature, and flight parameters
Predictive maintenance notifications
Customizable geofencing
