D-A4 Outdoor Thermal Imaging Telescope
D-A4 Outdoor Thermal Imaging Telescope
This product is an outdoor thermal imaging telescope, with advanced uncooled focal plane infrared detector and high-quality optical lens as the core, combined with a convenient operating system, small form factor design, functionality of the expansion of the spare parts. It has a long endurance and is durable and suitable for a variety of environments. It is the best choice for on-site inspection, preventive maintenance and other applications.
This product is an outdoor thermal imaging telescope, with advanced uncooled focal plane infrared detector and high-quality optical lens as the core, combined with a convenient operating system, small form factor design, functionality of the expansion of the spare parts. It has a long endurance and is durable and suitable for a variety of environments. It is the best choice for on-site inspection, preventive maintenance and other applications.
Description
Model | D-A4 | D-A74 |
Detector | uncooled focal | |
Resolution | 384×288 IR | 256×192 IR |
LCD | 720X540 | |
Focal | 19mm;25mm;35mm | 6.9mm;9.7mm |
Eyepiece | Monocular | |
Field of | 19.5°x14.7°; | |
Digital | 2x;4x | |
Wavelength | 8μm~14μm | |
Frame | 50Hz | 25Hz |
Palette | Rainbow/Hot | |
Focal | adjustable | |
Image | BMP | |
Battery | Built-in | |
USB | Micro | |
Operating | ≥6 | 4hours |
Weight | 541.2g | 513g |
Product | 187.3x68x68.2mm | 175x69x68mm |
Operating | -20℃~45℃ | |
Storage | -20℃~60℃ |
Additional information
Focal length | 25MM, 35MM |
---|
