DD500-AB portable handheld drone defense shield: 400MHz-6GHz full frequency detection, 2km precise interference, touch screen operation
SKU:DD500-AB
The DD500-AB is a portable, effective, and user-friendly drone defense tool designed for high-level security. It provides real-time drone detection and jamming capabilities, making it ideal for applications requiring rapid deployment, such as public security, military, and counter-drone operations.
Share on:
DD500-AB Portable Drone Detection and Jamming Shield
Overview
- Product Name: DD500-AB
- Type: Portable Drone Detection and Jamming Shield
- Key Features:
- Full-frequency detection
- Superb jamming in 6 frequency bands
- Fast and mobile deployment
- Highly practical
- Touchscreen design
Full-frequency Detection
- Frequency Range: 400MHz - 6GHz
- Coverage: Full coverage of mainstream drone models
Superb Jamming in 6 Frequency Bands
- Jamming Frequency Bands: 900MHz, 1.2GHz, 1.5GHz, 2.4GHz, 5.2GHz, 5.8GHz
- Jamming Distance: Up to **2km**
Touchscreen Design
- Screen Size: **3.5-inch**
- Features:
- Displays drone frequency bands, signal strength, etc.
- Allows free selection of detection frequency bands, direction finding, etc.
- Choose between separate communication interference, separate navigation interference, or full-frequency-band interference
Functional Integration
- Integrated Functions: Detection, jamming, display, and control
- Suitable For: Various individual duty scenarios such as public security, armed police, military, etc.
Product Details
- Components:
- 3.5-inch screen
- Battery
- Jamming button
- Power button
- Handle
Specifications
| Specification | Details |
|---|---|
| Detection Frequency Bands | 400MHz-1500MHz, 2200-2500MHz, 5150-5950MHz |
| Detection Distance | ≥2km (depends on working conditions and drone models) |
| Direction Finding Accuracy | ≤10° |
| Detection Angle | Horizontal: 0°-360° |
| Jamming Distance | ≥2km (depends on working conditions and drone models) |
| Jamming Frequency Bands | 900MHz, 1.2GHz, 1.5GHz, 2.4GHz, 5.2GHz, 5.8GHz |
| Operation Screen | 3.5-inch touchscreen |
| Jamming Coverage Angle | Horizontal ≥45°, Vertical ≥30° |
| Frequency Band Switching | Choose between separate communication interference, separate navigation interference, or full-frequency-band interference |
| Network Control | Can be connected with mobile terminal (APP) and back-end command and management platform at multiple levels (optional) |
| Standby Time | ≥20 hours, equipped with alarm detection function in standby mode |
| Working Temperature | -40℃ to +60℃ |
| Weight | ≤8kg (including the battery) |
| Size | 390mm x 160mm x 330mm (Length x Width x Height) |
