D-F460S V4 Stack: The Ultimate F405 Flight Controller & 60A ESC Combo for FPV Freestyle Drones
In the competitive world of FPV freestyle drones, having a reliable and high-performance flight stack is absolutely essential. The D-F460S V4 Stack represents the pinnacle of drone technology, combining a powerful F405 flight controller with a robust 60A 4-in-1 ESC in a compact 30x30mm package designed specifically for aggressive freestyle flying and high-performance applications.
Unmatched Processing Power and Flight Performance
At the core of the D-F460S V4 Stack lies the powerful STM32F405RGT6 processor, delivering exceptional computational capabilities for real-time flight control. Paired with the ultra-responsive ICM42688P gyroscope and SPL06 barometer, this flight controller offers unparalleled stability and responsiveness in all flight conditions.
The integrated 60A 4-in-1 ESC provides:
- Continuous 60A current per motor (70A burst)
- Support for 3-6S LiPo batteries
- Advanced protocols including DShot150-1200, MultiShot, OneShot, and ProShot
- Built-in current meter for power monitoring
Technical Specifications
| F405 V4 Flight Controller | |
|---|---|
| CPU | STM32F405RGT6 |
| Gyro | ICM42688P |
| Barometer | SPL06 |
| OSD | Supported |
| Black Box | 16MB |
| Motor Output | 8 channels |
| UART Ports | 5 channels |
| LED Strip | 4 in total |
| Buzzer | Supported |
| BEC Output | 3.3V/2A, 5V/2.5A, 12V/3A |
| Receiver Protocols | ELRS/CRSF/S.BUS/Frsky/Futaba/flysky/TBS Crossfire/DSMX |
| USB Connector | Type-C |
| DJI 03 Support | Yes |
| Camera Switching | Supported |
| Dimension | 36mm x 36mm |
| Weight | 9.4g |
| Mounting Holes | 30.5mm x 30.5mm |
| Firmware | RCF405V4 |
| 3060S 4-in-1 ESC | |
| Continuous Current | 60A x4 |
| Burst Current | 70A x4 |
| Input Signal | 150/300/600/1200 & MultiShot/OneShot/Proshot/PWM |
| Current Meter | Supported |
| Input Voltage | 3-6S LiPo |
| Firmware | Bluejay H-H-50 |
| Mounting Holes | M3 30.5mm x 30.5mm |
| Dimension | 40mm x 40.7mm |
| Weight | 10.4g |
Advanced Connectivity and Expansion Options
The D-F460S V4 Stack excels in connectivity and expansion capabilities, making it one of the most versatile flight stacks available. With support for virtually all popular receiver protocols including ELRS, CRSF, S.BUS, FrSky, Futaba, Flysky, TBS Crossfire, and DSMX, this stack ensures compatibility with your preferred radio system.
Key connectivity features include:
- 5 universal UART ports for maximum expansion capability
- Type-C USB connector for fast and reliable connections
- DJI 03 digital air unit support for HD FPV systems
- Camera switching capability for multi-camera setups
- SBUS and VTX jumpers for simplified wiring
- Multiple BEC outputs (3.3V/2A, 5V/2.5A, 12V/3A) for all your peripherals
Ideal Applications
With its compact dimensions (36mm x 36mm for FC, 40mm x 40.7mm for ESC) and optimized weight (9.4g FC + 10.4g ESC), the D-F460S V4 Stack is perfectly suited for:
- FPV Freestyle Drones: The powerful processing and precise control make this ideal for aggressive freestyle flying where responsiveness is critical.
- High-Performance Racing: The 60A ESCs with 70A burst capability ensure you’ll never lack power during intense races.
- HD Digital Builds: With native DJI 03 support, this is an excellent choice for pilots using digital HD FPV systems.
- Compact Builds: The stack’s small footprint makes it perfect for builds where space is at a premium.
- Long-Range Cruising: The efficient power system and comprehensive telemetry support make it great for extended flights.
Why Choose the D-F460S V4 Stack?
The D-F460S V4 Stack represents the perfect combination of processing power, electrical performance, and compact design. Whether you’re building an aggressive freestyle quad, a high-performance racer, or a compact HD digital rig, this flight stack delivers the capabilities you need to push your flying to the limits.
With its advanced sensor suite, robust 60A ESCs, and extensive connectivity options, the D-F460S V4 stands out as one of the most capable flight stacks in its class. The inclusion of a 16MB black box, on-board OSD, and multiple BEC outputs means you have all the tools needed for tuning and analyzing your flights, while the rugged construction ensures reliable performance even in demanding conditions.
For pilots looking to upgrade their drone’s core systems with a modern, feature-packed stack that won’t add unnecessary weight or bulk, the D-F460S V4 is an outstanding choice that delivers professional-grade performance in a compact package.
Ready to experience the difference a high-performance flight stack can make? Get your D-F460S V4 Stack today and take your drone’s performance to new heights!
